1
Electrochemistry
  • The study of the interchange of chemical and electrical energy.
2
Review of Terms
  •   oxidation-reduction (redox) reaction:  involves a transfer of electrons from the reducing agent to the oxidizing agent.


  •   oxidation:  loss of electrons


  •   reduction:  gain of electrons
3
Half-Reactions
  • The overall reaction is split into two half-reactions, one involving oxidation and one reduction.
  • 8H+ + MnO4- + 5Fe2+  ®  Mn2+ + 5Fe3+ + 4H2O
  • Reduction: 8H+ + MnO4- + 5e-  ®  Mn2+ + 4H2O
  • Oxidation:  5Fe2+  ®  5Fe3+ + 5e-
4
Galvanic Cell
  • A device in which chemical energy is changed to electrical energy.
5
Anode and Cathode
  • OXIDATION occurs at the ANODE.
  • REDUCTION occurs at the CATHODE.
6
Cell Potential
  • Cell Potential or Electromotive Force (emf):  The “pull” or driving force on the electrons.
7
Standard Reduction Potentials
  • The E° values corresponding to reduction half-reactions with all solutes at 1M and all gases at 1 atm.
  • Cu2+ + 2e-  ®  Cu           E° = 0.34 V vs. SHE
  • SO42- + 4H+ + 2e-  ®  H2SO3 + H2O
    •       E° = 0.20 V vs. SHE
8
emf and Work
9
Free Energy and Cell Potential
  • DG° = -nFE°
  • n = number of moles of electrons
  • F = Faraday = 96,485 coulombs per mole of electrons
10
Concentration Cell
  • . . . a cell in which both compartments have the same components but at different concentrations.
11
The Nernst Equation
  • We can calculate the potential of a cell in which some or all of the components are not in their standard states.
12
Calculation of Equilibrium Constants for Redox Reactions
  • At equilibrium, Ecell = 0 and Q = K.
13
Batteries
  • A battery is a galvanic cell or, more commonly, a group of galvanic cells connected in series.
14
Fuel Cells
  • . . . galvanic cells for which the reactants are continuously supplied.
  • 2H2(g) + O2(g)  ®  2H2O(l)
  • anode:  2H2 + 4OH-  ®  4H2O + 4e-
  • cathode:  4e- + O2 + 2H2O  ®  4OH-
15
Corrosion
  • Some metals, such as copper, gold, silver and platinum, are relatively difficult to oxidize.  These are often called noble metals.
16
Electrolysis
  • . . . forcing a current through a cell to produce a chemical change for which the cell potential is negative.
17
Stoichiometry of Electrolysis
  • How much chemical change occurs with the flow of a given current for a specified time?
  •       current and time ® quantity of charge ®
    • moles of electrons ® moles of analyte ®
    • grams of analyte
